Performance characteristics
Intelligent hydraulic control: The hydraulic pilot system provides comfortable operating performance and flexible adjustment performance for the whole machine. The first-class brand hydraulic parts ensure the reliable operation of the hydraulic system of the whole machine;
Technological leadership: The patented floating technology of the power head can greatly protect the drill pipe thread and increase the service life of the drill pipe;
Reliable operation: The power head adopts a motor + reducer structure, and through the gear rack structure, the push and pull speed is fast and the operation is reliable;
Efficient construction: High and low speed push and pull rotation system, the plunger variable motor realizes high and low speed push and pull of the power head, increases the adaptability of the drilling rig to working conditions, and improves the construction efficiency of the drilling rig;
Customer customization: Supports diversified customer needs.
| XZ130F | XZ180F | XZ230F | XZ360F |
| Cummins National IV | Cummins National IV | Cummins National IV | Cummins National IV |
| 81/2200 | 96/2200 | 118/2200 | 154/2200 |
| 135 | 180 | 230 | 380 |
| 40 | 45 | 55 | 40 |
| 3200 | 4500 | 7000 | 13200 |
| 230 | 195 | 190 | 140 |
| 100 | 180 | 250 | 400 |
| 4 | 4 | 8 | 8 |
| φ52×1.8 | φ60×2 | φ60×3 | φ73/76/83×3 |
| —— | —— | —— | —— |
| —— | —— | —— | —— |
| 18 | 18 | 20 | 20 |
| 5 | 5.5 | 8.5 | 10 |
| 4200×1680×2170 | 4200×1800×2200 | 6100×2230×2300 | 6200×2280×2450 |
| 1. Fully automatic gripper; 2. Double anchoring; 3. Mud antifreeze; 4. Wireless travel; 5. Thread oil application. | 1. Fully automatic gripper; 2. Double anchoring; 3. Mud antifreeze; 4. Wireless travel; 5. Thread oil application. | 1. Cab; 2. Air conditioning; 3. Fully automatic gripper; 4. Double anchoring; 5. Mud antifreeze; 6. Wireless travel; 7. Thread oil application. | 1. Fully automatic gripper; 2. Double anchoring; 3. Cab; 4. Air conditioning; 5. Mud antifreeze; 6. Wireless travel; 7. Thread oil application. |
4.2m ultra-short size, meets the requirements of blue-plate vehicle transportation and is convenient for transfer. | 1. Patented floating technology of power head protects drill pipe threads and increases drill pipe life; 2. Multi-speed output technology is used for push-pull and rotation, which is energy-saving and efficient in construction and improves construction efficiency by 30%. | 1. Aerospace-grade rotary joint, with a service life increased by 35%; 2. Open frame shed, easy to maintain and repair. | |
