| Quantity: | |
|---|---|
| parameters | Work quality(kg) | 17000(Equipped with a traction frame) 18771(Equipped with a soil-loosening device) | 18500 | 18000 | 19000 |
| Minimum turning radius(mm) | 4015 | 4400 | 4400 | 4500 | |
| Grounding specific pressure(kPa) | 67.2 | 32.5 | 31.6 | 26.9 | |
| Engine | Engine model | WP9H/ National IV emission standard | |||
| Rated power/Rated speed(kW/rpm) | 140/1900 | 140/1900 | 140/1900 | 140/1900 | |
| External dimensions | Overall dimensions of the whole machine(mm) | 5292×3454×3157 | 5415×4177×3201 | 5415×4177×3201 | 5615×4177×3201 |
| (Length/Width/height) | |||||
| Walking performance | Forward speed(km/h) | F1:0-3.8、F2:0-6.6、F3:0-10.6 | F1:0-2.7、F2:0-3.7、F3:0-5.4、F4:0-7.6、F5:0-11 | ||
| Backward speed(km/h) | R1:0-4.9、R2:0-8.5、R3:0-13.6 | R1:0-3.5、R2:0-4.9、R3:0-7、R4:0-9.8 | |||
| Ground clearance(mm) | 400 | 400 | 400 | 400 | |
| Chassis system | Track center distance(mm) | 1880 | 2300 | 2300 | 2300 |
| Track plate width(mm) | 510/560/610 | 950/1100 | 950/1100 | 1100 | |
| Grounding length(mm) | 2430 | 2935 | 2935 | 3140 | |
| Number of track plates (single side/piece) | 37 | 42 | 42 | 44 | |
| Track chain pitch (mm) | 203.2 | 203.2 | 203.2 | 203.2 | |
| Number of rollers (single side) | 2 | 2 | 2 | 2 | |
| Number of supporting wheels (single side) | 6 | 7 | 7 | 7 | |
| Fuel tank capacity | Fuel tank (L) | 295 | 295 | 295 | 295 |
| Working hydraulic oil tank (L) | 75 | 75 | 75 | 75 | |
| Working device | Blade type | Straight tilting shovel | Straight tilting shovel | Straight tilting shovel | Straight tilting shovel |
| Width of the scraper(mm) | 3454 | 4177 | 4177 | 4177 | |
| Blade height(mm) | 1136 | 988 | 988 | 988 | |
| The lifting height of the shovel(mm) | 982 | 1060 | 1060 | 1029 | |
| Soil shoveling depth(mm) | 511 | 506 | 506 | 505 | |
| The shape of the soil-loosening tool | Three teeth | / | / | / | |
| Loosening depth(mm) | 592 | / | 1 | / | |
| The soil-loosening device raises the height(mm) | 572 | / | I | / | |
