| Machine Parameters | ||
| Machine Weight | kg | 13500 |
| Power | kw/rpm | 89/2200 |
| Standard Bucket Capacity | m³ | 0.6 |
| Optional Bucket Capacity | m³ | / |
| Tractive Force | kN | 130 |
| Climbing Ability | % | 70 |
| Engine Parameters | ||
| Engine Model | / | Cummins F4.5 |
| Working Type | / | 4-stroke, water-cooled, electronically controlled direct injection |
| Maximum Torque | Nm/rpm | 500/1300 |
| Number of Cylinders | / | 4 |
| Cylinder Displacement | L | 4.5 |
| Emission Standards | / | National Four |
| Hydraulic System | ||
| System Type | / | Negative flow |
| Main Pump Type | / | Inclined plate type double variable displacement piston pump |
| Main System Pressure/Boost Pressure | Mpa | 34.3/37 |
| Swing Circuit Working Pressure | Mpa | 25 |
| Travel Circuit Working Pressure | Mpa | 34.3 |
| Pilot Pump Type | / | Gear Pumps |
| Volume Parameters | ||
| Fuel Tank | L | 240 |
| Engine Oil | L | 12 |
| Hydraulic System | L | 130 |
| Hydraulic Oil Tank | L | 145 |
| Urea Tank Capacity | L | / |
| Working Scope | ||
| Arm Length (standard) | mm | 4600 |
| BOOM Length (standard) | mm | 2500 |
| Maximum Digging Radius | mm | 8420 |
| Maximum Digging Depth | mm | 5505 |
| Maximum Digging Height | mm | 8465 |
| Maximum Unloading Height | mm | 5885 |
| Minimum Swing Radius | mm | 2830 |
| Maximum Arm Digging Force | kN | 69 |
| Maximum Bucket Digging Force | kN | 108 |
